E2D2

알림

Model Number	E2D2-10000
Size (W x D x H, mm)	1100 x 1720 x 2300
Installation Method	Universal roller rack or Anchoring
Inside Space(U)	42
Usable Space(U)	33
Nominal IT Capacity(kW)	10
Cooling Method	InRow DX & Water Combined
Cooling condenser	All-in-one
UPS	10kw 19" Rack mounted
Battery	8~10min @60% Load
Input Voltage	208-240Vac, 60Hz
Available configuration	Indoor / Outdoor
IP Grade	IP55
Power Distribution Unit	Metered, Networked rack PDU * 2
Environment Mornitoring	Networked EMU & FMS
Net Weight	750kg
Warranty	1year

Model Number	E2D2-5000
Size (W x D x H, mm)	700 x 1520 x 1900 (With out Foot 100)
Installation Method	Universal roller rack or Anchoring
Inside Space(U)	23
Usable Space(U)	16
Nominal IT Capacity(kW)	5
Cooling Method	Top DX & Water Combined
Cooling condenser	All-in-one
UPS	5kw 19" Rack mounted
Battery	8~10min @60% Load
Input Voltage	208-240Vac, 60Hz
Available configuration	Indoor / Outdoor
IP Grade	IP55
Power Distribution Unit	Metered, Networked rack PDU * 2
Environment Mornitoring	Networked EMU & FMS
Net Weight	380kg
Warranty	1year

Model Number	E2D2-9000	E2D2-7000
Size (W x D x H, mm)	1000 x 1200 x 2000 (With out Foot 100)	900 x 1200 x 2000 (With out Foot 100)
Installation Method	Universal roller rack or Anchoring	Universal roller rack or Anchoring
Inside Space(U)	42	42
Usable Space(U)	39(UPS 별도)	39(UPS 별도)
Nominal IT Capacity(kW)	10	5
Cooling Method	InRow DX & Water Combined (Option)	InRow DX
Cooling condenser	Outdoor condenser	Outdoor condenser
UPS	10kw 19" Rack mounted	5kw 19" Rack mounted (Option)
Battery	8~10min @60% Load	8~10min @60% Load
Input Voltage	208-240Vac, 60Hz	208-240Vac, 60Hz
Available configuration	Indoor	Indoor
IP Grade	IP54	IP42
Power Distribution Unit	Metered, Networked rack PDU * 2	Networked rack PDU * 2
Environment Mornitoring	Networked EMU & FMS	Networked EMU & FMS
Net Weight	400kg(UPS별도)	300kg(UPS별도)
Warranty	1year	1year

Model	Server	Storage	N/W	SDWAN	Backup & DR	Security	Rack	기타 Solution	용도
Entry	Rack Server x 1 (2 socket)	VSAN	L2/L3 Switch x 1	Option	Option (가상화 backup)	Option	Half	-	소규모 (10VM 이하)
Mid-range	중형 HCI x 2	VSAN	L2/L3 Switch x 2	Option	내장 backup & 내장 DR	Option	Half	-	소규모 (10VM 이하)
Enterprise	중형 HCI x 4	VSAN	L2/L3 Switch x 2	Option	내장 backup & 내장 DR	Option	Full	Option (Container, Private Cloud)	대규모 (50VM 이상)
Ent-HD	Blade Server	SAN	SND	Option	가상화 backup & DR	Option	Full	Option (Container, Private Cloud)	고집적 대규모 (100VM 이상)
Ent-MC	HCI or Blade Server	SAN or VSAN	L2/L3 Switch or SDN	Option	내장 backup & 내장 DR or 가상화 Backup & DR	Option	Full*2	Option (Container, Private Cloud)	미션 크리티컬 대규모 (100VM 이상, 이중화)
Edge	Edge Computing Server	-	L2/L3 Switch x 2 + IoT Gateway + Wireless	-	-	Option	Half or Full	-	IoT Edge computing
Container	Container HCI	VSAN	SND	Option	내장 backup & 내장 DR	Option	Half	-	Container 환경 구축
VDI for RPA	소형 HCI x 2	VSAN	L2/L3 Switch x 2	-	내장 backup & 내장 DR	Option	Half	RPA	VDI RPA (50user 이하)
